Lead-Zinc Ore Grinding Mill

Large pieces of lead-zinc ore are crushed by a crusher until they reach a fineness (15mm–50mm) suitable for entry into a grinding mill.

The crushed lead-zinc ore fragments are transported via an elevator to a storage hopper, from which they are fed uniformly and at a controlled rate into the grinding chamber of the mill.
For fine powder production, equipment such as the LM Vertical Roller Mill, MTW European-style Mill, or 6X Intelligent European-style Mill (featuring thin-oil lubrication) is typically used. For ultrafine powder, the LUM Ultrafine Vertical Mill or MW Ring-Roller Micro-powder Mill is preferred. For coarse powder, the CM European-style Coarse Powder Mill or a direct-flow centrifugal mill is used.

The ground material is processed through a powder classifier. Particles that do not meet the required fineness are separated and returned to the main mill for further grinding.

Particles that meet the required fineness are carried by an airflow through ducts into a dust collector, where they are separated and gathered. The collected finished powder is then transported from the discharge outlet to a finished-product silo, from where it is either loaded into bulk tanker trucks or processed through an automatic bagging machine.
